Product specifications:
Power supply: AC110-220V
Voltage adjustment: Discharge: 0.00-30.00 V, minimum step width 0.01 V
Charging: 0.00-22.00V, minimum step size 0.01V
Current setting: Discharge: 0.05-10.00 A, minimum step width 0.01 A (automatic current limitation when the power exceeds the limit)
Charging: 0.05-5.00 A, minimum step width 0.01 A (maximum current limited by supply current)
Discharge mode: DSC-CC: Constant discharge current for testing battery capacity or supply current
DSC-CP: Constant discharge power to simulate devices with constant power or to test the power supply
Charging method: Standard charging: support of nickel hydrogen, nickel chromium, lithium, iron lithium, lead acid
CHG-CV: Special charging with constant current and constant voltage, only for batteries
Automatic charging and discharging: Supports automatic charging, discharging and charging mode to test battery capacity
Voltage test: 0,002-4,500 V (low voltage) Accuracy is 0,003 V, error ± 0,5%
4,50 V ez30,00 V (high voltage) Accuracy up to 0,01 V, error ± 0,5%Current test: 0.05-10.000A, accuracy 0.005A, error ± 0.5%
Capacity test: 10Ah, resolution is 0,001Ah
10AH-100Ah, resolution is 0.01Ah
Over 100 Ah, resolution 0.1 Ah
Connection method: Four-wire detection, separate wiring of voltage and current channels to ensure measurement accuracy
LCD display: voltage, current, capacity, time, power, energy test data
Computer online: dedicated USB to TTL serial port (mini USB interface, non-ordinary USB cable), computer control, curve drawing, calibration benchmark test, firmware upgrade, cyclic charging and discharging.
Tip: A ZivV V is connected to the positive battery, A_V_ is connected to the negative battery
