Features:
Name: Inclined Hole Chamfering Drill Bit
Material: HSS
Quantity: 4pcs
Shank: Round handle
Specification:
head diameter * shank diameter * length
2-5: 10 * 6 * 45mm/0.39 * 0.24 * 1.77in (Invert holes within the range of 2MM-5MM)
5-10: 14 * 8 * 47mm/0.55 * 0.31 * 1.85in (Invert holes within the range of 5MM-10MM)
10-15: 21 * 10 * 39mm/0.83 * 0.39 * 2.65in (Invert holes within the range of 10MM-15MM)
15-20: 28 * 12 * 46mm/1.1 * 0.47 * 3.35in (Invert holes within the range of 15MM-20MM)
Attention: Chamfer drills need to be paired with bench drills for operation, and continuous cooling is required during the application process
Scope of application:
Applicable to workpieces with hardness below 25hrc, such as thin aluminum plate, insulating board, PVC board, wood board, etc., not suitable for stainless steel
Package included:
4pcs ×Inclined Hole Chamfering Drill
