WARNING

Any digital AC voltmeter, AC ammeter, frequency meter, dual-display meter for current and voltage, or thermometer should not be used to measure on devices such as batteries, electric motors of electric vehicles, non-sine wave inverters in frequently starting fields, soft starters, frequency converters, or the downstream of load switches,otherwise the instrument may be burned out!

All instruments have an error margin of ±2%, so please be cautious if you are particular about this!

Parameter

Lighting Source: LED;
Color of lamps: R-red, Y-yellow, G-green, B-Blue, W- White
Volt.: AC60V--500V;
Nature of supply: AC ;
Rated Temp : T90;
Life of continuous working: Typically over 30,000 hours. The end of life for a lamp is not usually a sudden failure;
3. Main technical parameters
Environmental Temperature: -25+55;
Working under vibration frequency 2-80Hz,acceleration at 0.7g;
Relative Air Humidity: ≤98%;
Pollution rank is three grade and installation category is III;
Protection Degree: Head IP65
Voltage of working frequency: 2.5kV (AC valid value), 1min;
Leakage Index: CT1≥100;
Frequency: AC 50-60Hz
Error ± 1%
